Laser Pipe Cutting Machine
01
Precision High-speed 3D Full-automatic Laser Tube Cutting Machine
Product Detail
With a focus on laser pipe cutting machines, we are the manufacturer of choice. primarily manufacture fully automated laser pipe cutting machines, precision laser pipe cutting machines for incredibly small tubes, and high-efficiency three-dimensional, five-axis multifunctional laser pipe cutting machines. We can alter the laser machines to suit your needs. In industries like electronic communications, medical devices, and industrial manufacturing, our G240P Precision High-speed 3D Full-automatic Laser Tube Cutting Machine is extensively utilized for pipe processing.
Product introduction
G240P Accuracy With laser power ranging from 3000w to 6000w, this high-speed 3D fully automatic laser tube cutting machine is made to cut a variety of small and medium-sized pipes. It has a machine bed that is attached to the side for stability, increased loading capacity, and improved shock resistance. About 40mm short tailings are produced with great material usage when two-chuck cutting is done in reverse. Processing accuracy is ensured by a servo support mechanism, double cutting stations, and a two-chuck structure. An automated loading and unloading platform increases productivity and reduces labor expenses. able to bevel 45° and cut Φ120mm circular tube (optional). single tube length up to 6250 mm.
Features
1. Quick and extremely stable; typically, 2500–3500 segments per hour are specified.
2. Adopt a widely used configuration tube that is high-cost, high-performing, and appropriate for precision machining of big and small tubes.
3. Double-chuck control is more adaptable, and fool-like operation may be achieved by directly adjusting the pipe length.
4. Different cutting kinds include elliptical, round, square, and angle pipes, as well as channel, angle, and l-beam pipes, and other arbitrary pipes.
Application
This G240P Precision High-speed 3D Full-automatic Laser Tube Cutting Machine can effectively cut various types of small and medium-sized pipes in 3D.
Parameters
|
Model |
G240P |
|
Laser Power (W） |
1500-6000 |
|
Cutting range (MM) |
Circumference:10-240 |
|
Repeat positioning accuracy (MM) |
±0.02 |
|
Pipe length range(MM ) |
≈6250 |
|
Machine size (MM) |
L*W*H:8856*2886*2172 |
|
Body + Rack size (MM) |
Fully automatic(L*W*H):8856*2886*2172 |
|
Machine weight（T） |
≈3.5 |
|
Acceleration(G) |
≈1 |
|
Tailings length(MM) |
≈100 |
Samples
Structures
-
1. Laser source: Max/Raycus
-
2. Laser cutting head: Ray Tools
-
3. Operating system: Bochu FSCUT3000
-
4. Servo motor: Huichuan
-
5. Water chiller: Hanli
Details
|
G240P Precision High-speed 3D Full-automatic Laser Tube Cutting Machine parameter |
|
|
Parameter |
Supplier |
|
Laser source |
Raycus / Max |
|
Laser head |
RayTools |
|
Water cooling unit |
Hanli |
|
Chuck |
Changzhou Biite |
| Servo motor |
Huichuan |
| Guide rail slider |
Taiwan TBI |
| Pipe processing range |
10-240MM |
| Configuration of material rack |
Optional receiving rack (2 pneumatic supports as standard) |
| Minimal cutting length |
1mm |
| Loading length |
Automatic : 3500- 6250mm |
| Thickness of cutting material | Depending on laser power (8.0mm thickness per 3000W) |
| Cutting slit width |
0.1-0.15mm |
| Machine tool repeated positioning accuracy |
±0.02mm |
| Maximal acceleration |
1G |
| Voltage |
380V/50Hz |
| Total weight of equipment |
About 3.5 tons |
| Equipment dimension |
Length8856*width2886*height2172 |
