G120F manual feeding high-speed laser tube cutting machine

China QianGang Company specializes in the production and manufacturing of high-speed laser tube cutting machines, and is the originator of laser tube cutting machines. The company possesses outstanding technical strength and rich experience. Among them, the G120F manual feeding high-speed laser tube cutting machine can complete the pipe cutting task quickly and accurately. It features high cutting precision, smooth and flat cutting edges without burrs, which greatly improves quality and efficiency.

    Contact us
    product details

    Product Detail

    We are a manufacturer specializing in the production of high-speed laser tube cutting machines. We can tailor laser equipment according to your specific needs. Our G120F manual feeding high-speed laser tube cutting machine has been widely applied in various fields such as hardware accessories, hardware furniture, bathroom, medical equipment, sports equipment, automobile production, building decoration, electrical equipment, elevator equipment and other major fields of metal pipe processing. Specifically for stainless steel pipe accessories, automobiles, motorcycles, electric vehicles, bicycles, air conditioning, railings, guard rail, anti-theft net, shelves and other industries pipe processing.

    Product introduction

    The G120F manual feeding high-speed laser tube cutting machine has achieved an extremely small tail waste area in its design. This not only saves materials but also reduces subsequent processes, thereby lowering labor costs. This equipment can precisely meet the processing requirements of various and complex pipe materials.
    In terms of core power technology, its laser power has a flexible adjustment range, ranging from 1500 watts to 6000 watts. Whether it is for precise cutting of thinner pipes or efficient cutting tasks for slightly thicker pipes, it can perform excellently and effortlessly.
    主图

    Features

    1.Time and labor-saving with a simple structure and easy operation.Efficiency is 5–6 times higher than that of conventional pipe cutting machines.
    2.Follow-through cutting: Standard integrated height regulator ensures effortless processing of deformed pipes.
    3.This is a model that doesn't require drawing,the operation is simple and convenient, and the cutting range is wide. Various specifications of cut pieces can be selected, including oval, circular, square, channel steel, angle steel, I-beam steel, and other various-shaped pipes.
    4.There is no blind area in tailings, which reduces the subsequent processing workload and saves materials: the theoretical tailings cutting depth of this equipment is approximately 60 mm, which significantly reduces material loss.

    Application

    The G120F manual feeding high-speed laser tube cutting machine demonstrates unparalleled versatility in metal pipe processing, whether addressing automotive structural components like exhaust pipes and chassis brackets, or crafting medical-grade tubing for surgical instruments and implantable devices;whether processing round/square tubes for agricultural machinery components or tackling complex profiles needed in aerospace fuel systems;whether handling stainless steel kitchenware or electronic cooling fins, the G120F manual feeding high-speed laser pipe cutting machine redefines precision through its combination of speed, flexibility, and minimal heat-affected zones.
    2111

    Parameters

    Model

    G120F

    Laser Power (W）

    1500/2000/3000/6000

    Cutting range (MM)

    Circumference:10-120

    Repeat positioning accuracy (MM)

    ±0.02

    Pipe length range(MM )

    ≈6500

    Body + Rack size (MM)

     Manual (L*W*H): 8004*1212*1916

    Weight（kg）

    Main Body ≈2000

    Acceleration(G)

    ≈1.6

    Tailings  length(MM)

    ≈60

    Samples

    2111

    Structures

    • product-description360n

      1.Laser source: Max

    • 475751af-67cd-4c96-8602-2523775fdc5b

      2.Laser cutting head: Weihong

    • 971bae0e-3326-4c2a-ad4b-4ec090489634

      3.Operating system: Weihong Control System

    • 图片13

      4.Servo motors: (Weihong)

    • product-description7nn3

      5. Water chiller: Hanli

    Details

    Modification

    G120F

    Resonator (W)

    1500

    Maximum pipe length(mm)

    6500

    Maximum diameter of round pipe(mm)

    Ø 10-120

    Maximum profile size Pipes(mm)

    口 10*10 - 120*120

    Maximum rotational speed, W-axis(rpm)

    200

    Maximum travel speed, X, Y axis(m/min)

    120

    Acceleration (G)

    1.6

    Positioning accuracy(mm)

    ±0.05

    Repositioning accuracy(mm)

    ±0.02

    Chuck drive

    Pneumatic

    Steady rest drive

    Pneumatic

    Length of the receiving table(mm)

    1500 - 3000

    Dimensions of the machine (mm)

    Manual (L*W*H):  8004*1212*1916
    Semi-auto Feeding(L*W*H): 8004*1747*1916

    Weight (kg)

    Main Body: 2000

    Total power (kw)

    17

    Operating temperature (°C)

    5 - 35

    Voltage （V）

    380V/50Hz
